型号Type

PHS(2)-300

工件最大质量（kg）Max.dia.of works

300

最大回转直径（mm）Maximum rotation diameter

φ550

工件直径范围（mm）Workpiece diameter range

φ40～220

伺服电机功率（kw）Servo motor power

5.5

伺服驱动器(kw) Servo driver power

5.5

两支承间距离（mm）Dis.berween supports

～600

跑合工位（一次性跑合主轴件数）（mm）

Rotating station (number of workpieces of disposable spindle)

2

信号通道数量Number of signal channels

2

温度传感器分辨率Temperature sensor resolution

0.1℃

主轴跑合转速（rpm）Spindle rotation speed

～24000

可检测温度变化范围Detectable temperature range

-50℃～150℃

温度传感器数量（套）Number of temperature sensors

4

圈带传动处直径范围mm  Diameter range at belt drive

Φ20～Φ250

检测结果打印格式 Printing format of test results

纸质

USB接口 打印机  USB interface printer

机架外形尺寸mm  Overall dimension of frame

1030X710X575
